Specifications
Output Power | 1600W |
Input Voltage （V） | 36VDC-72VDC |
Output 12V main | +12V/132A max |
Output +12V sb | +12V/2.1A |
Dimension (L)*(W)*(H) (mm) | 185*73.5*40 |
Air Flow direction Normal airflow(FR)/Reverse airflow(RF) | FR |
Operating Temperature | 0℃～50℃ |
Standard | CCC;CQC;FCC;TUV |
Efficiency（%） | Gold |
EMI | CLASS A |
