Specifications
Dimensions(W*D*H) | 104.8 mm x 485 mm x 40.8 mm | |
Weight | ≤ 3.0 kg | |
Heat dissipation | Force air cooling | |
Input Voltage | 90~290 Vac | 188~400V DC |
Input frequency | 45~65 Hz，Frequency:50/60 Hz | |
Input current | AC: 19A max | DC: 18A max |
Power factor | ≥ 0.99 (100% load) | |
Output Voltage | 54Vdc~57Vdc | |
Output power | 3000 W (176~290 Vac or 188~400V DC) | |
Operating temperature | -5℃~+55℃ | |
Storage temperature | -40℃~+85℃ | |
Relative Humidity | 5%-95%（Non-condensing） | |
Altitude | ≤5000m | |
MTBF | 250,000 hours | |
Noise | ≤ 55 dB (35℃) | |
Standard | TUV,CE,CB, UL Compliant: IEC62368-1; EN62368-1; UL62368 | |
