Specifications
Dimensions(W*D*H) | 106.5 mm x 485 mm x 41 mm | |
Weight | ≤ 3.0 kg | |
Heat dissipation | Force air cooling | |
Input Voltage | -38Vdc~-72Vdc | |
Input current | 63 A | |
Output Voltage | 53.5Vdc | |
Output power | 2200 W | |
Operating temperature | -5℃~+55℃ | |
Storage temperature | -40℃~+85℃ | |
Relative Humidity | 5%-95%（Non-condensing） | |
Altitude | ≤5000m | |
MTBF | >300,000 hours | |
Standard | TUV,CE,UL,IEC62368-1 | |
