Specifications
Output Power | 600W | |
Dimensions(W*D*H) | 90 mm x 214.5 mm x 39.6 mm | |
Weight | ≤ 1.1 kg | |
Heat dissipation | Force air cooling | |
Input Voltage | 90~290 Vac | 190~290V DC |
Input frequency | 45~66 Hz，Frequency:50/60 Hz | |
Input current | AC: 8A | DC: 4A |
Power factor | ≥ 0.98 (50%~100% load) | |
Output Voltage | 12Vdc | |
Operating temperature | -25℃~+55℃ | |
Storage temperature | -40℃~+70℃ | |
Relative Humidity | 5%-95%（Non-condensing） | |
Altitude | ≤5000m | |
MTBF | >250,000 hours | |
Noise | ≤ 53 dB (35℃) | |
Standard | TUV,CE,CB, EAC, NRTL, CCC Compliant: IEC60950-1,EN60950-1, IEC62368-1; EN62368-1; GB4943.1 | |
