Specifications
Dimensions(W*D*H) | 95.5 mm x 208 mm x 40.8 mm | |
Weight | ≤ 1.5 kg | |
Heat dissipation | Force air cooling | |
Input Voltage | 85~300 Vac | 85~420 Vdc |
Voltage system | 220Vac or 110Vac | HVDC: 240Vdc/336Vdc |
Input frequency | 45~66 Hz，Frequency:50/60 Hz | |
Input current | <13 A | |
Power factor | ≥ 0.99 (> 50% load at 230 Vac) | |
Harmonic | ≤ 3% (> 50% load at 230 Vac) | |
Output Voltage | 42~58Vdc， Normal Voltage：53.5Vdc | |
Output power | 2000 W (176~300 Vac ) | 2000 W ( 200 ~420 Vdc ) |
Operating temperature | -40℃~+80℃（no derating under 55℃） | |
Storage temperature | -40℃~+80℃ | |
Relative Humidity | 5%-95%（no condensation） | |
Altitude | ≤5000m | |
MTBF | >500,000 hours | |
Noise | ≤ 45 dB (25℃，full load) | |
Standard | TUV,CE,UL,CB Compliant: UL60950-1,IEC60950-1,EN60950-1,CAN/CSA C22.2 No.60950 -1,EN55022 Class B,EN55024,EN61000-3-2, EN61000-3-3,ETSI EN300 386,ETSI,EN301489 ,ITU-T K.20 YD 5098-2005 5KA | |
