Specifications
Dimensions(W*D*H) | 105 mm x 269 mm x 40.8 mm | |
Weight | ≤ 2.2 kg | |
Heat dissipation | Force air cooling | |
Input Voltage | 85~300 Vac | |
Input frequency | 45~66 Hz，Frequency:50/60 Hz | |
Input current | <21 A | |
Power factor | ≥ 0.97 (50%~100% load) | |
Harmonic | ≤ 5% (> 50% load at 230 Vac) | |
Output Voltage | 42~58Vdc, Nominal Voltage：53.5Vdc or 57Vdc | |
Output power | 4000 W (176~290 Vac ) | 4000W~1600W ( 175 ~85 Vac ) |
Operating temperature | -40℃~+75℃ | |
Storage temperature | -40℃~+75℃ | |
Relative Humidity | 5%-95%（Non-condensing） | |
Altitude | ≤5000m | |
MTBF | >500,000 hours | |
Noise | ≤ 55 dB (45℃) | |
Standard | TUV,CE,CB Compliant: UL60950-1,IEC60950-1,EN60950-1,CAN/CSA C22.2 No.60950 -1,EN55022 Class B,EN55024,EN61000-3-2, EN61000-3-3,ETSI EN300 386 | |
